Safety Steel Wire Rope Cable With Lanyard Hooks Double Casting Hook YW86538

Safety Steel Wire Rope Cable With Lanyard Hooks Double Casting Hook YW86538
Safety Steel Wire Rope Cable With Lanyard Hooks Double Casting Hook YW86538 Safety Steel Wire Rope Cable With Lanyard Hooks Double Casting Hook YW86538 Safety Steel Wire Rope Cable With Lanyard Hooks Double Casting Hook YW86538 Safety Steel Wire Rope Cable With Lanyard Hooks Double Casting Hook YW86538 Safety Steel Wire Rope Cable With Lanyard Hooks Double Casting Hook YW86538 Safety Steel Wire Rope Cable With Lanyard Hooks Double Casting Hook YW86538

Large Image :  Safety Steel Wire Rope Cable With Lanyard Hooks Double Casting Hook YW86538

Product Details:
Place of Origin: GUANGDONG, CHINA
Brand Name: YW
Certification: CE RoHS
Model Number: YW-86538
Payment & Shipping Terms:
Minimum Order Quantity: 1000 PCS
Price: Negotiable
Packaging Details: 2pcs / PP bag, 35*25*18cm Carton
Delivery Time: 8 - 15 work days
Payment Terms: T/T, Western Union
Supply Ability: 2,000,000 PCS a Month
Detailed Product Description
Item Name: YW-86538 Cable Material: Stainless Steel, Galvanized Steel
Part Size: 45mm Eyelet Material: Brass / Stainless Steel / Steel
Diameter: 2mm Cable Length: Any Length Available
Length: 500mm Sample: Free Sample Available For Existing Dimension
Application: Light Fixture, Hanging Systems, Picture Hanging MOQ: 1000pcs
Lead Time: 8-15 Business Days
High Light:

Wire Rope Cable With Lanyard Hooks

,

Double Casting Hook Wire Rope Cable

,

30kg Load Wire Rope Sling

Double Casting Hook Same Way Steel Wire Rope Cable Lanyard Hooks YW86538



Features:



* There have two hooks at the end of the wire rope terminal.

* This safety cable is made of high-quality material, it can use for a long time.

* These Safety cables are suitable for various products of stage light: moving head light, par light.

* Safety cable wires hook can connect different stage lights in parties, weddings, and other festivals.

* Quick and easy to attach and remove.

Specification:



 Material   Stainless steel  Type   Lanyard button
 MOQ   1000 PCS   Construction   1x7;7X7;1x19 etc
 Wire Diameter   ∅2mm   Carton Size   35*25*18cm
 Wire Length  Customized  Lead Time   8-15 workdays
 Break load   30kg  Payment Terms

  T/T,Western Union,Paypal




Description:



* 7×7: Six 1×7 outside strands are cabled around a 1×7 strand center. This is the most standard cable construction. This produces a very flexible cable with good cycle life and excellent breaking strength

* 1×7: Six wires are laid around one center wire. This strand is more flexible than a 1×3. This construction is commonly used for push-pull applications and for conductive needs with low flexibility.

* 1×19: Twelve wires are laid around a 1×7 center. This construction is used for more flexible needs than a 1×7 in push-pull and conductive applications. A 1×19 strand is almost as high a breaking strength as a 1×7 strand with the same diameter.

* 7×19: Six 1×19 strands are cabled around a 1×19 center strand. This is the most flexible standard construction for cable. This cable gives you a high cycle life but has a lower breaking strength and is more costly than a 7×7 cable.





Wire Rope and Cable Available:



1.304 Stainless Steel Wire,7X7;
2.Galvanized Steel Wire;
3.Nylon in black and white color and PVC jacketed cable in transparent
 colors.





Application:



* Promotional displays (hanging of signs)

* Hardshell cases (lid restraint)

* Display cases (lid restraint, shelf support)

* Retail Security (security cable for electronics, clothes, expensive manuals, etc.)

* HVAC Heating and cooling ductwork (support lanyards for ducts and pipes)

* Material Handling (hanging support lanyards, pulley cables)

* Specialized vehicles (security stainless steel lanyards for release pins, lid restraints)

* Lawn and garden equipment (security lanyards for release pins, lid restraints)

* Seats (seat restraint lanyard)

* Tailgates and Doors (latch lanyard, support lanyard, door restraint)





About us:



We have numerous capabilities that allow us to meet your specific needs and be the industry leader for custom cable assemblies.

* CNC Machining Capabilities—Yingwei has the capability to quickly make custom component parts to meet a variety of customers’ needs.

* Electric Cutting—Automatic fuse cutting enables Yingwei to achieve precise length requirements while eliminating any frayed ends.

* Swaging—Yingwei’s manufacturing facility offers various size swaging machines to meet your diameter requirements.

* Tensile Testing—All tensile testing is done in-house at our facility. Our quality department can provide a material cert with the shipment if you need.
