Payment & Shipping Terms:
|Gripper Size:||40*34mm||Ceiling Size:||40*35mm|
|Wire Length:||2000mm, Customized||MOQ:||500pcs|
|Lead Time:||7-15 Business Days||Sample:||Free Sample Available For Existing Dimension|
180° Adjustable Ceiling Cable Hanging System,
Ceiling Cable Hanging System Light Fittings,
1.5mm Diameter Cable Hanging System
|Material||Brass + steel||Surface treatment||Nice nickel/ chrome/ Zinc plating or other color painting|
|MOQ||500 PCS||Construction||1x7;7X7;1x19 etc|
|Wire Diameter||∅1.5mm||Carton Size||35*25*18cm|
|Wire Length||2000mm, customized||Lead Time||7-15 workdays|
|Break load||20kg||Payment Terms||
* Time-Saving: Allows quick installation and instant adjustment;
* Fast and easy to suspend lighting fixtures during the installation;
* No tools needed to adjust cable length, up or down, down or up – as often as you like;
* Designed for the suspension of surface light fittings, suitable for use with a large range of commercial lighting.
This is a braided support cable for the suspension system.
The cable can be sold in various lengths to work with almost any ceiling height.
It has a terminal attached at one end. With this system, the cable is inserted
into the ceiling coupler on one end and the cable glider on the other.
No tools are required to do this. Once the system is installed the cable can
be adjusted by sliding it through the cable glider and releasing the top plunger when needed.
1. Choose a Suspension Point
Your system can be ceiling or wall-mounted, with applications
hanging freely or tensioned between two fixed points;
2. Pick a Cable
Our stainless steel aircraft cable comes in several diameters
and lengths ranging from 1.0mm~3.0mm;
3. Select a Gripper
A range of designs and options, all with self-gripping technology,
offer a secure and elegant solution for any fine art installation.
An attractive cable hanging system, adds an elegant touch to your window displays:
*Display systems for signs, posters & literature;
*Adjustable wire and fittings allow fine height adjustment;
*Dual-Sided displays to advertise both front and back;
*Perfect for art displays, estate, retail shop, bank, and museums.
The upper and lower ends of the suspension kit can be used for the same, this kit is supplied together with a 1.5*2000mm cable plus a three hols suspension ceiling whose height can be set using the inbuilt self-locking clutch mechanism. Simply push the button to release the grip while fine adjustments are made.
This kit is specially put together for supermarkets hanging POS promotions and aisle signs, but can also be used for other suspended ceiling sign hanging applications.
