Make The Installation Easy And Flexible!
|
Product Details:
Payment & Shipping Terms:
|
| Wire Material: | 304 Stainless Steel /Galvanized Steel Wire | Wire Thickness: | Ø1.2mm |
|---|---|---|---|
| Wire Length: | Customize | Dia Cast Size: | 10*16mm |
| Application: | Use For Hanging Kit | Others: | OEM/ODM Acceptable |
| High Light: | wire rope fittings,wire rope cable slings |
||
Fuse Cut Ended Stainless Wire Rope Sling ,Eyelet Terminals Wire Rope Assemblies
Our 7x7 and 7x19 construction, stainless steel, and galvanized aircraft cable are primarily used for thelanyards. If required, lanyards can also be manufactured using PVC or nylon-jacketed cable, which are available in a diverse collection of jacket colors including clear.
In order to provide our customers with a quick turnaround on standard lanyards, we provide a complete range of off-the- shelf fittings available in various materials. Some standard fittings include threaded studs, oval sleeves, stop sleeves, button stops, ball fittings, eyelets, tabs, and thimbles.
This wire rope sling is a part of the suspension system.
7X7 304 Stainless Steel Wire,with a end of dia casting,
The dia casting size is Ø16*10mm,Used for applications where you have a hight ceiling,
curved or slope ceiling or difficult installation.
Description
| 1. Item Name | Eyelet Terminals Wire Rope Sling |
| 2. Material | 304 Stainless Steel Wire |
| 3. Dia Cast Size | 16*10mm |
| 4. Cable Diameter and Length | Ø1.2*1000mm;Or Customize |
| 5. Finishing Color | Silver |
| 6. Application |
Wire ropes are used in a range of industries such as mining, transportation,and material handling among others that require various heavy-duty lifting applications. |
| 7. Safe Working Load | 20KG(For reference only) |
| 8. Content | 1*Stainless Steel wire with Dia Cast terminal loop end |
| 9. Wire Rope and Cable Available |
1.304 Stainless Steel Wire,7X7; |
Aircraft Cables, also known as wire ropes, have diameters ranging from 1.0 to 3.0m and are
omposed of six steel strands wound around a seventh steel stranded core.
This stranded steel core adds strength and crush-resistance to the cable. Aircraft cable is classified by the number of strands in the cable multiplied by the number of wires in each strand. For example, the notation 7×7 indicates that the cable has seven strands made up of seven wires in each strand. Similarly, the notation 7×19 indicates that the cable has seven strands made up of nineteen wires in each strand.
The greater the number of wires, the greater the flexibly of the cable. We are offering cables 7×7 or 7×19 galvanized or stainless steel (304 or 316) medium-to-high tensile strength aircraft cable.
If a lanyard using standard, off-the- shelf fittings doesn't work for your application, We have the capability to manufacture custom fittings to perfectly meet your unique requirements. By utilizing our in-house machine shop, we can precision-machine any type of end fitting as well as provide custom tabs, eyelets, and other custom hardware to your specification.
